BB100

BB100 Specification

a. Bar Diameter: 100 mm (3.93 inches)

b. Boring Diameter: 150 – 500mm (6 – 19.7 inches)

c. Max. Stroke: 500mm (19.68 inches)

d. Torque at Bar:

e. 70 Nm (51 ft lbs)

f. Power Option: Electric and Hydraulic

Application

• - Gearbox parts and housings

• - Various applications in shipbuilding, including rudder parts and stern tubes

• - Driveshaft housing

• - A-frame supports

• - Hinge pins

• - Turbine casing

• - Engine Bedplates

• - Cylinder Liner locations

• - Clevis plate bores
